The winch is designed for lifting and transport operations in construction, installation and other works, as well as for the assembling of construction lifting devices, drilling devices, platform hoists, concrete mixers of various types, and others.

The winch is not intended for lifting people.

Ambient class U, category 2 as per GOST 15150-69.

The winch is designed to operate under the following conditions:

• environment - non-explosive;
• ambient temperature: +40°С - 40°С;
• operating position - fastening on level ground;
• operating mode – low duty;

Pulling force of rope – 6.3 kN

Rope speed on the first layer – 0.58 m/s

Coiling length of a drum – 130 m

Rope diameter – 8.1-8.3 mm

Rope length – 80 m

Brake type – TKG-160
braketorque - 0.1 kN*m (kgf*m)

Type of gear unit: C2U-160-31.5-21

ratio – 30.72

Type of motor: AIR 100 S4

capacity – 4.0 kW

Dimensions - 840 x 835 x 805 mm

Winch weight w/o rope, kg
