PUPROSE

The electric winch is designed for lifting and transport operations, cargo shifting in construction, installation and other works. It can be used for the assembling of mechanisms and devices required in construction, installation and other works. Operating position of winch is fastening on level ground.

The winch is not intended for lifting people.

Ambient class U, category 2 as per GOST 15150-69.

The winch is designed to operate under the following conditions:

• environment - non-explosive;
• ambient temperature: +40°С - 40°С;
• operating position - fastening on level ground;
• operating mode – low duty;
• operating voltage – 380 V, current frequency – 50 Hz.

TECHNICAL CHARACTERISTICS

• Pulling force – 420 kgf
• Rope speed on the first layer – 0.72 m/s
• Coiling length of a drum – 80 m
• ЭлElectric motor capacity – 3.0 kW
• Rope diameter – 6.9 mm
• Gear unit - 1C2U-160
• ratio – 31.5
• Brake TKG-160
• Winch dimensions - 920х620х820 mm
• Winch weight w/o rope, kg – 235
